Maucotools Portable Multi-function Machine Tools: Model C40 Dual System Std 250
Have one to sell?
ConditionNew
1 available
New
Portable Multi-function Machine Tools: Model C40 Dual System Std 250 allows for carry-welding and boring from 45mm to 250mm.
The C40 Dual System is the new line of portable boring machines by MAUCOTOOLS.
The new patents make this machine, available in three versions, a powerful tool, all-around, accurate and simple to use.
The machine is a dual system, innovative solution that makes it separable. Built in two separate parts that can
do independent machining.
Three models: STD 250, also available in the Plus version, STD 400 and STD 600. The supplied accessories, if combined with the optional ones, can cover all the demands of welding and of the boring of precision, for the holes with a diameter between 45mm and 600mm.
Machining phases, boring and welding.
Application fields:
The versatility of our machines make it usable in almost all industrial sectors: earth moving, oil industry, shipbuilding, railway, wind power, etc.
The following are the full specifications of the C40 Dual System STD 250. (For the other models available, up to 600mm, please contact us for full specifications)
works executables performed:
boring
drilling
tapping
internal overlay welding
external overlay welding
smoothing orthogonal planes (with extra kit)
Seeger Circlips (with extra kit)
Technical features
chain transmission
permanently lubricated
feed and rotation torch with single motor
bar: mm 40
length shaft: 21000 mm
Longitudinal stroke: with step da 200 mm
welding: at continuous spiral
telescopic welding torch
110 V power supply also available on request
advancement stroke: 200 mm
rotation shaft rpm: 60-140 / 200-470
conical clamp for mounting machine
Dati di lavorazione
alesatura interna: mm 45/250
alesatura esterna: con kit extra
saldatura interna: mm 45/250
saldatura esterna: mm 45/250
foratura: mm 10-32 (fino a 45 con adattatore optional)
maschiatura: mm 10-45 (con adattatore optional)
spianatura piani ortogonali (con kit extra)
campo di lavoro ridotto: mm 22 a 250 (con kit extra)
campo di lavoro esteso: non disponibile
Motor shaft
type: single phase AC 2 speed with adjustable speed
motor shaft power: w 1800 v 230
minimum torque Nm: 37
maximum torque Nm: 110
Rated speed:
speed I: 60-140 rpm
speed II: 200-470 rpm
Feed Motor
type: AC
rated voltage: 110V 50/60Hz
current rating: 1Amp
feed: manual / automatic
speed: 0-160 rpm
max speed: 160 rpm
feed system: electromechanical
Electronic Control Panel
main switch
emergency switch
reversing feed left/right
rotation speed control
feed speed control
reversing direction of rotation CW / CCW
