New D-F CK5225V-ATC | Lathes, VTL (Vertical Turret Lathe)

D-F 2.5m (98.438) Double Column CNC Vertical Turning Lathe Model CK5225V-ATC (With 1.75m Vertical Ram Stroke + H. D. Ram Size).

Other D-F CNC VTLs Videos:
VIDEO TURNING: https://www.youtube.com/watch?v=a03sOoyRN0s
VIDEO MILLING: https://www.youtube.com/watch?v=NL4V-8-iAAs

Machine Specifications:
Main SpecificationsunitModel
CK5225V
Max. vertical turret cutting diametermm2500
Diameter of worktablemm2250
Max. height of work-piecemm2500
Max. weight of work-pieceton16
CNC system　Siemens 828D
Max.Torque of table turningN80000
Speed steps of worktablestep2 Steps
Speed of worktablerpm0.5-63
One CNC ram-section sizemm240x240
Right ram machining capacityKN35
Horizontal travel of ram-X axismm1300
Vertical travel of ram-Z axismm1750
Rapid travel speed of tool postmm/min4000
Rapid travel speed of crossbeammm/min350
Cross beam travelmm2100
Main motor powerKW75
