Used 2008 MG AK-350-G | Rolls, Plate Bending (incl Pinch)

3000mm x 50mm (10 x 2) MG 3-Roll Hydraulic Plate Bending Machine Model AK350 - New in 2008
3-roll hydraulic plate bending machine with dual pre-pinch planetary configuration
- Made in Italy
Capacity rolling plate thickness 50 mm
-Plate width 3000 mm
-Pre-pinch on plate thickness 40 mm
-reference to plate yield strength 245 N/mm2.
-Minimum rolling dia. 600 mm with medium thickness.
-upper roll size 480 mm -side rolls 440 mm
-useful working length of rolls 3100 mm
Machine configuration and accessories installed:
-rolls hardening treatment
-conical plates hydraulic bending attachment
-digital position readouts.
-3 rolls driven hydraulic motorized with independent axial gear box on each roll.
-Machine fully hydraulic operated with centralized power unit dual pumps high pressure.
-Overload safety hydraulic protection.
-Rotation of the 3 rolls hydraulic synchronized.
-Greasing free technology with sealed bearings and self lubricated bushings.
-Centralized console with electric commands easy one-man operation.
-Safety devices in compliance with Intl. machine tools regulation.
-Delivery term: Ex-Works loaded on truck
- Certificates with the machine:
- CE quality certification made in Italy.
- Service Manuals and schematics in English.
Shipping dimensions: machine
600 x 235 x h 265 cm -weight 25100Kgs
Console 80 x120 x h 80 weight 100Kgs
