New WAFUM TNC1400/3000 B25 | Lathes, Oil Field & Hollow Spindle

New 55.125" x 120" Wafum CNC Oil country flat bed turning center Model TNC 1400/3000 B25 with 25 spindle hole. Fanuc 0i TF CNC controls

CNC Oil Country Lathe Type SOH 1400.30.25 .
Controller Fanuc Oi-TF
Swing over bed 1385 mm (55") .
Swing over crosslide 940 mm (37")
Width of bed 800 mm (1000mm with auxiliary guideway ).
Distance between centers 3000 mm (120")
Spindle bore 635 mm (25") .
Spindle nose Manufcaturer definition
Spindle speed ( 4 steps ) 2- 250 rpm
Leadscrew Ball screw 80 mm
Tailstock quill diam. 200 mm , taper mc 7
Main spindle motor 30 kw
Machine weight 18000 kg .

Further standards equipment
- AC spindle motor
- Automatic way lubrication system
- Coolant system
- Headstock oil cooler
- Hardened guideways
- Electric cabinet air conditioner
- Chip conveyor
- Live center mt 7
- 2-Door type splash guard
- Operating and service manuals .
